Description
Use With CLAMP P115205
Cross Reference
AIR MAZE SEFB1252
BELL B12005
CASE/CASE IH NB125005
CATERPILLAR 3I0007
FLEETGUARD AH19497
HAVAM HD1935
HIFI FILTER SAB125005
JOHNSON TOWERS JT3862
KIRLOSKAR F698301000
LOESING 020260
LOESING 20260
OSHKOSH 1754710
PARKER HANNIFIN CORPORATION 2121214400
SCHUPP AG SL12909
SDMO 30801080801
WALGAHN MOTORENTECHN 00810033
WALGAHN MOTORENTECHN 810033
WOODGATE WGA1145
Parameter
Outlet Diameter: 139.7 mm (5.50 inch)
Body Diameter: Maximum 317.5 mm (12.50 inch)
Body Length: 228.6 mm (9.00 inch)
Efficiency 99.9
Efficiency Test Std: ISO 5011
Rated Flow LR: 22.6 m³/min (798 cfm)
Rated Flow MR: 30 m³/min (1059 cfm)
Rated Flow HR: 35.4 m³/min (1250 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECB
Primary Application LEROI 43867
Type: Primary
Style: Round
Brand: DuraLite™
Media Type: Cellulose
Packaged Dimensions
Packaged Length: 32.51 cm (12.80 inch)
Packaged Width: 32.26 cm (12.70 inch)
Packaged Height: 32.77 cm (12.90 inch)
Packaged Weight: 2.78 kg (6.13 lb)
Packaged Volume: 0.03 m3 (1.21 ft3)
