Description
Filter inside:
External filter P783543
Internal filter P783544
Or filter kit: X770684=(P783543+P783544)
Cross Reference
CASE/CASE IH 87324470
DONALDSON SPB130048
HIFI FILTER SAH01C13ADP001
ING. ENEA MATTEI AG05AAX017
NEW HOLLAND 87517150
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 254 mm (10.00 inch)
Body Diameter: Maximum 266 mm (10.47 inch)
Body Length: 325 mm (12.80 inch)
Rated Flow LR: 11 m³/min (388 cfm)
Rated Flow MR: 16 m³/min (565 cfm)
Rated Flow HR: 20 m³/min (706 cfm)
Restriction: LR: 9.81 mbar (3.94 inch H2O)
Restriction: MR: 19.61 mbar (7.87 inch H2O)
Family: SPB
Packaged Dimensions
Packaged Length: 46.99 cm (18.50 inch)
Packaged Width: 42.01 cm (16.54 inch)
Packaged Height: 57.00 cm (22.44 inch)
Packaged Weight: 7.19 kg (15.86 lb)
Packaged Volume: 0.11 m3 (3.97 ft3)
