Description
Filter inside:
External filter P775631
Internal filter P775298
Cross Reference
AUSA 450120010
BOMAG 05730061
BOMAG 5730061
DONALDSON FPG057505
GEHL 781360157505
IKARUS 7000305505
LOESING 020031
LOESING 20031
Parameter
Outlet Diameter: 51 mm (2.01 inch)
Inlet Diameter: 51 mm (2.01 inch)
Body Diameter: Maximum 146 mm (5.75 inch)
Overall Length: 343 mm (13.50 inch)
Body Length: 230 mm (9.06 inch)
Rated Flow LR: 1.7 m³/min (60 cfm)
Rated Flow MR: 2.6 m³/min (92 cfm)
Rated Flow HR: 3.4 m³/min (120 cfm)
Restriction: LR: 9.81 mbar (3.94 inch H2O)
Restriction: MR: 19.61 mbar (7.87 inch H2O)
Restriction: HR: 29.42 mbar (11.81 inch H2O)
Style: Radialseal
Family: FPG
Brand: RadialSeal™
Packaged Dimensions
Packaged Length: 22.00 cm (8.66 inch)
Packaged Width: 19.00 cm (7.48 inch)
Packaged Height: 37.01 cm (14.57 inch)
Packaged Weight: 1.05 kg (2.31 lb)
Packaged Volume: 0.02 m3 (0.55 ft3)
