Description
23um version P566258
8um version P566256
5um version P566255
Cross Reference
ARGO 7234577 P566247 standard capacity；P566257 high capacity
ARGO 7234578 P566247 standard capacity；P566257 high capacity
ARGO 7242023 P566247 standard capacity；P566257 high capacity
ARGO 7242024 P566247 standard capacity；P566257 high capacity
ARGO 7242531 P566247 standard capacity；P566257 high capacity
BALDWIN H8014
BALDWIN H9014
BOSCH REXROTH R928016742
CARQUEST R64C10GV
CATERPILLAR 3I0616
DENISON DE0411V8L10
DONALDSON DT83103914UM
EPPENSTEINER 168310XH10SLS000V
EPPENSTEINER 168310XH10XLS000V
FAIREY ARLON R831H3912A
FILTREC R434G10
FILTREC R434G10V
FINN EQUIPMENT FFPAVL11132C10
FINN FILTER FFPAVL11132C1
FLEETGUARD HF30340
FLEETGUARD HF30341
GENERAL ELECTRIC 165A205FY75
GRAINGER 52YR90
HILCO PH73901CG P566247 standard capacity；P566257 high capacity
HILCO PH73901CGV P566247 standard capacity；P566257 high capacity
HILCO PH73911CG P566247 standard capacity；P566257 high capacity
HY PRO HP83103912MB
HY PRO HP8310L3912MV
HYDAC 10639D12BN
HYDAC 11439D12BN
HYDAC 2060639
HYDAC 2060846
HYDAC 2070199
HYDAC H831039010BN
INTERNORMEN 05830010VG10BP39
INTERNORMEN 301056
LIEBHERR 8636964
LUBER FINER LH4565
LUBER FINER LH95069V
LUBER FINER LH95610
MAIN FILTER R434G10V
MP FILTRI MP3209
NAPA 7293 ,R64C10GV
PALL HC8300FDS39Z ,HC8310FCS39H ,HC8310FCS39Z ,HC8310FDS39H ,HC8310FDS39Z ,HC8310FKS39H ,HC8310FKS39Z ,HC8310FUS39H ,HC8310FUS39Z
PARKER 927946 ,928085 ,932874Q ,PR3459
PTI DP83250KFV
PUROLATOR 9326798 ,9326832
REPLACED BY P164566 ,P171045
SCHROEDER 39QPMLS7B ,39QPMLZ10V ,SBF830039Z10B ,SBF830039Z10V
SEPARATION TECHNOLOGIES 8830L12B39
STAUFF SP300E010B
SWIFT SF83103912UMV
TRIBOGUARD 83103912UM
VICKERS V0411V8L10
VMC HF171045
WESTERN FILTER E0411B8L10 ,E0411V8L10
WIX 57293 ,557293 ,R64C10GV
WOODGATE WGPS8339
ZINGA Y3912LND
Parameter
Seal Material Viton
Outer Diameter: 150.8 mm (5.94 inch)
Inner Diameter: 104.4 mm (4.11 inch)
Overall Length: 960.1 mm (37.8 inch)
Efficiency Beta 1000 12 micron
Collapse Burst 10.3 bar (149 psi)
Flow Direction Outside-In
Style: Cartridge
Series W041
Brand: DT High-Performance
Media Type: Synthetic
Packaged Dimensions
Packaged Length: 17.78 cm (7.00 inch)
Packaged Width: 17.78 cm (7.00 inch)
Packaged Height: 102.87 cm (40.50 inch)
Packaged Weight: 6.35 kg (13.99 lb)
Packaged Volume: 0.03 m3 (1.15 ft3)
