Description
12um version P566257
8um version P566256
5um version P566255
Cross Reference
AONALDSON DT83103925UM
ARGO 7234579 P566248 standard capacity；P566258 high capacity
ARGO 7234580 P566248 standard capacity；P566258 high capacity
BOSCH REXROTH R928016743
DENISON DE0411V8L20
EPPENSTEINER 168310XH20SLS000V
EPPENSTEINER 168310XH20XLS000V
GRAINGER 1XPR9
HILCO PH73903CG P566248 standard capacity；P566258 high capacity
HILCO PH73903CGV P566248 standard capacity；P566258 high capacity
HILCO PH73905CGV P566248 standard capacity；P566258 high capacity
HY PRO HP8310L3925MB ,HP8310L3925MV
HYDAC 11439D25BN
HYDAC 2060847
HYDAC H831039020BN
LUBER FINER LH95620V
PALL HC8310FCT39H
PALL HC8310FCT39Z
PALL HC8310FDT39H
PALL HC8310FDT39Z
PALL HC8310FKT39H
PALL HC8310FKT39Z
PALL HC8310FUT39H
PALL HC8310FUT39Z
PARKER 932875Q
PTI DP83250JFB
PTI DP83250JFV
SCHROEDER 39QPMLZ25V
SWIFT SF83103925UMV
TRIBOGUARD 83103925UM
VICKERS V0411V8L20
WESTERN FILTER E0411B8L20
WESTERN FILTER E0411V8L20
ZINGA Y3925LND
Parameter
Seal Material Viton
Outer Diameter: 150.8 mm (5.94 inch)
Inner Diameter: 104.4 mm (4.11 inch)
Overall Length: 960.1 mm (37.8 inch)
Efficiency Beta 1000 25 micron
Collapse Burst 10.3 bar (149 psi)
Flow Direction Outside-In
Style: Cartridge
Series W041
Brand: DT High-Performance
Media Type: Synthetic
Packaged Dimensions
Packaged Length: 0.59 FT
Packaged Width: 0.59 FT
Packaged Height: 3.36 FT
Packaged Weight: 5.77 kg (12.70 lb)
Packaged Volume: 0.03 m3 (1.18 ft3)
